SD95

A specially designed system for fabricating entrance doors of high aesthetics with high quality materials

SD95 is a Supreme system specially designed for fabricating entrance doors of high aesthetics with high quality materials. The main characteristic of the system is the heavy duty thermal-break profiles which, in combination with glass or aluminum panels, respond to the latest architectural trends thanks to the following main characteristics:

  • Maximum energy efficiency thanks to extremely low thermal insulation coefficient (Ud<1,0W/m2K)

  • Anti-distortion polyamides to accommodate the deflection of the door due to the difference between inside and out temperatures

  • Continuous central gasket for better air and water sealing along with improved thermal insulation performance

  • High level of sound reduction

  • Concealed, barrel or surface mounted hinges

  • A variety of different multi points security locks which offer enhanced security levels

Frame depth 95 mm
Sheet depth 104 mm
Minimum visible construction height 106 mm
Sash weight up to 300kg
Maximum thickness of glazing to 60mm
Type of insulation 54mm reinforced polyamide
Thermal - EN ISO 10077-2 Uf to 1,1 W / m2 * K
